Description
MinarcMig Evo 200 offers Automatic and Manual mode set-up for precise welding quality and arc ignition monitored and controlled by Kemppi’s adaptive arc regulation system. Each model features a large graphical interface guiding the user during set-up. With MinarcMig Evo 200 you can simply set the plate thickness and start welding, and the materials selection for ferrous, stainless steel, aluminium and CuSi brazing filler wires satisfies a wide variety of industrial applications. PFC power source technology offers the ultimate energy economy with a power factor of 0.99. MinarcMig Evo can also be used efficiently with extra long power supply cables of more than 100 meters long, allowing for optimum welding utility in site welding environments.
FEATURES:
• Precise weld quality and arc ignition
• PFC technology for ultimate energy efficiency and increased welding time due to reduced machine cooling breaks
• Suitable for mains network or generator use
• Designed for use even with 100 m long supply cables
• Automatic and manual operation modes
• Large graphical display that guides the user
• Intuitive plate thickness regulation (mm) for fast set-up
• Lightweight and portable at 13 kg
• Use with 1 and 5 kg spools of Fe, FCW, Ss, Al and CuSi filler wires
• Select from convex, flat or concave weld bead profile
• Welding gun (3 m), shoulder strap and cable set included as standard
MACHINE PACKAGE:
• Kemppi Minarc Mig EVO 200 – Power source
• 3 metre Mig Gun (MMG22)
• 3m Earth return cable and clamp
• 4.5M gas hose
• Carry strap
TECHNICAL DATA:
• Connection voltage 1~ 50/60 Hz: 230 V ±15%
• Fuse (delayed): 16A
• Welding range: 20 A/15 V – 200 A/26 V
• Open circuit voltage: 70-75 V
• Minimum generator power: 4.2 kVA
• Standards: IEC 60974-1, IEC 60974-5, IEC 60974-10, IEC 61000-3-12
• Operating temperature range: -20 – +40 °C
• Degree of protection: IP23S
• Wire spool diameter: max. 200 mm
• Wire spool weight, max. 5 kg
• External dimensions LxWxH: 450 × 227 × 368 mm
• Weight (no accessories): 13 kg
• Output 35% ED: 200 A/24 V
• Output 60% ED: 160 A/22 V
• Output 100% ED: 120 A/20 V
